Introduction to the 2022 MakeX Explorer Arena
The kit does not include the MakeboX.
1. Basic information
2022 MakeX Explorer Arena
| Name | 2022 MakeX Explorer Arena |
|---|---|
| SKU | P1090040 |
| EAN | 6928819513662 |
| Package type | Paper box |
| Package size | 365355310mm |
| 1175210115mm | |
| 2386.9 * 2426.9 mm（map） | |
| 1175210115mm | |
| Gross weight (including packaging) | 30.775kg (1085.556oz) |
| Others | Remote control and battery not included |
2. Overview
This kit contains a map, a frame, props and other parts needed for the 2022 MakeX Explorer competition, which can be used for offline training and competition hosting.
3. Parts list
Make sure the following parts are included in the kit. If there is any missing part, contact our after-sales service or distributors.
| Name | Quantity |
|---|---|
| Flat Beam 1126 | 16 |
| MakeX Board Blue&Black | 4 |
| MakeX Board Red&Black | 4 |
| Flat Beam 1126 | 4 |
| Octagonal Pillar-600 | 2 |
| Octagonal Pillar-250 | 8 |
| Octagonal Pillar-125 | 2 |
| Middle Board A | 1 |
| Middle Board B | 2 |
| Flat Beam Lock | 40 |
| Extension Connector | 4 |
| 90° Connector | 16 |
| Octagonal Pillar Cover | 24 |
| Rectangular Nut M4 | 30 |
| Plate | 3 |
| Yellow Ball 70mm | 16 |
| Green Ball 100mm | 6 |
| Yellow Cube 70mm | 5 |
| Lean Beam-248 | 4 |
| Lean Beam-424 | 4 |
| Lean Beam-504 | 4 |
| MakeboX Bracket | 1 |
| Height Setting Bar | 8 |
| Flag Bucket | 2 |
| 1 | |
| Max in Red | 1 |
| Screw M3*8 | 2 |
| Flag Bucket | 2 |
| 1 | |
| Max in Blue | 2 |
| Screw M3*8 | 2 |
| Screw M4*40 | 20 |
| Screw M4*14 | 4 |
| Screw M4*8 | 6 |
| Hex Nut M4 | 20 |
| Screw M6*12 | 16 |
| Screw M6*16 | 2 |
| Hex Nut M6 | 18 |
| Spacer 4.2730 | 20 |
| Hook-and-Loop Fastener 20mm (Hook) | 1 |
| Hook-and-Loop Fastener 21mm (Loop) | 2 |
| Goal Net | 2 |
| EVA Tape 20*8mm | 2 |
| Cable Tie | 100 |
| Transparent Tape | 1 |
| 3M Double-sided Nano Tape | 1 |
| Hex Allen Key T30 | 1 |
| Allen Key 5mm | 1 |
| Screwdriver Cross&2.5mm | 1 |
4. Assembly instruction
After checking the number of parts, refer to the following document to assemble the 2022 MakeX Starter Arena. 2022 MakeX Explorer 碳锁先锋_场地搭建步骤_说明书_V1.0_D1.1.2_ KD010421000_preview.pdf
5. More information
Getting started with the 2022 MakeX Explorer Educational Competition Kit：makeblock.com/en/docs/cyberpi/22explorer-start mBlock online help：makeblock.com/en/docs/cyberpi/mbot2-mobile-coding mBot2 operation guide: makeblock.com/en/docs/cyberpi/mbot2-start Introduction to the 2022 MakeX competitions and kits：makeblock.com/en/docs/cyberpi/22makex
